| Place of Origin: | China |
|---|---|
| Brand Name: | TMTeck |
| Certification: | CE |
| Model Number: | TG-8060 |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | carton |
| Delivery Time: | 4-7 work days |
| Payment Terms: | T/T, Western Union,Paypal |
| Supply Ability: | 20PCS/Two weeks |
| Warranty: | 2years | Resolution: | 0.1℃(0.2︒F) |
|---|---|---|---|
| Waterproof Class: | IP67 | Weight Of The Whole Machine: | Around 14g |
| Temperature Drift: | Omit | Recorded Capacity: | 16000 Dots |
| Product Size: | 63mm X 33.5mm (No Including The Package) | ||
| High Light: | Automatically Record PDF Temperature Recorder,Low Power Consumption PDF Temperature Recorder,CE PDF Temperature Recorder |
||
lTemperature measurement for long-term sea transportation
lRecord the temperature during fresh milk product transportation
lUltra-thin compact design
lLow-power consumption & long-time endurance
lOver-temperature alarm & prompt
lEncrypted PDF report
lAutomatically record the temperature fluctuation
lOwn IP67 waterproof performance.
lAutomatically record the temperature fluctuation / Low-power consumption & long-time endurance
Brief introduction
TG-8060 PDF Temperature recorder is aiming at liquid storage medicine, vaccine, blood, Cold chain logistics, food, chemical industry, agriculture, meteorology, pasturage etc fields, which is used to record the temperature change automatically in a long time. The recorder owns IP67 waterproof performance, ultra-thin compact appearance, low-power consumption & long-time endurance, over-temperature alarm, it can automatically generate unmodifiable PDF reports. With this PDF recorder, the user needn’t install the driver program, after recording, the user can directly insert it into USD interface of the computer, it will automatically generate PDF file, and the report is encrypted, so as to ensure the file is unmodifiable & safe.
Typical application
Temperature record for fresh milk product transportation; temperature record for medical blood & vaccine transportation and storage; record for seeds & microorganism cultivation process; temperature record for chemical agent transportation / storage in laboratory or during industrial production ; temperature record for biological & scientific container; temperature record for long-time sea transportation; temperature record for museum or library or machinery room and so on.
Main characteristics:
A kind of automatic long-time temperature change recording product
Ultra-thin compact design
Temperature recorder owns IP67 waterproof performance.
Low-power consumption, long-time endurance.
Over-temperature alarm or prompt
Directly generate unmodifiable PDF report.
No need install driver program when using PDF recorder.
After completing record, the user can directly insert it into USB interface of the computer.
Automatically generate PDF report and the report is encrypted.
Make sure the material is unmodifiable & safe.
Performance& index
| Measured temperature | -35℃-80℃(-31-176︒F) | Recorded days | Default : 60 days (The user can customize among 30 days, 90 days, 120 days, 180 days). |
| Resolution | 0.1℃(0.2︒F) | LED | Green LED & Red LED to indicate the status |
| Storage temperature | -35℃-80℃(-31-176︒F) | Communication mode | Connect it to USB directly (no need install any software). |
| Measured precision | 0.5℃/0.9︒F | Waterproof class | IP67 |
| Temperature drift | Omit | Weight of the whole machine | Around 14g |
| Document format | Battery | CR2450 wide-temperature battery ( one year of endurance at room temperature) | |
| Recorded capacity | 16000 dots | Product size | 63mm x 33.5mm (No including the package) |
| Sampling interval | Select from 10 seconds to 12 hours (default setting: 5 min) | Alarm setting | Three groups of high temperature / Two groups of low temperature (Default setting: High temperature alarm threshold: 8℃; Low temperature alarm threshold: 2℃) |
| Sensor | NTC Built-in high sensitivity sensor | ||
| Start mode | The default mode is to press the key for 5 seconds, and the machine will defer for 10 min to start working. (The user can customize the start timing and modify the deferring time). | Parameters | Highest temperature, lowest temperature, average temperature, temperature curve, Temperature & time history table; Time zone, Start time, End time, Accumulated time etc. |
Temperature record for biological & scientific & technological container etc cultivation
Temperature record for medical blood & vaccine transportation & storage
Temperature record for chemical agent transportation / storage in laboratory or during industrial production
Temperature record for museum or library or machinery room and so on.
Temperature record for seeds & microorganism cultivation
Temperature record for fresh milk product transportation
DATA LOG SAMPLE PICTURES
