10 Step Wedge NDT Ultrasonic Test Block

Basic Information
Place of Origin: China
Brand Name: TMTeck
Certification: ASTM E797
Model Number: 10 step test blocks
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Carton, 0.5kg
Delivery Time: 4-6 work days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 50PCS/Two weeks
Detail Information
Product: Step Test Block Material: 1018 Steel, Stainless Steel
Step: 10 Type: NDT Accessories
Version: MM, INCH Function: Calibration,Testing Calibration Function
Package: Plastic Carrying Case Color: Steel
High Light:

Wedge ultrasonic test block

,

10 Step ultrasonic test block

,

NDT Ultrasonic Test Block


Product Description

10 Step test block Wedge Testing Ultrasonic Test Block 1018 steel/304 stainless steel Ultrasonic thickness gauge



Special step block for thickness and linearity calibration. There are three versions of the block available.
The 10-Step Inch version S-10-IN is made to TMTeck and goes from 0.100” to 1.000” in 0.100” increments. Face measures 0.8” x 0.8”.
The 10-Step Metric version S-10-MM goes from 1 to 10mm in 1mm increments.
The 10-Step Metric version S-10-MM-1 goes from 2.0 to 20.0mm in 2.0mm increments. Step face on both metric versions is 20mm x 20mm.



Model PIC Description
10 Step Test Block
S-10-MM 10 Step Wedge NDT Ultrasonic Test Block 0

MM,1018 steel, 10step test block

Thickness:1mm/2mm/3mm/4mm/5mm/6mm/7mm/8mm/9mm/10mm

size:200*20mm

S-10-MM-SS 10 Step Wedge NDT Ultrasonic Test Block 1

MM, 304 Stainless Steel, 7step test block

Thickness:1mm/2mm/3mm/4mm/5mm/6mm/7mm/8mm/9mm/10mm

size:200*20mm

S-10-MM-1 10 Step Wedge NDT Ultrasonic Test Block 2

MM,1018 steel, 10step test block

Thickness:2mm/4mm/6mm/8mm/10mm/12mm/14mm/16mm/18mm/20mm

size:200*20mm

S-10-MM-SS-1 10 Step Wedge NDT Ultrasonic Test Block 3

MM, 304 Stainless Steel, 7step test block

Thickness:2mm/4mm/6mm/8mm/10mm/12mm/14mm/16mm/18mm/20mm

size:200*20mm

S-10-IN 10 Step Wedge NDT Ultrasonic Test Block 4

INCH,1018 steel, 10step test block

thickness:0.100” 0.200” 0.300” 0.400” 0.500” 0.600” 0.700” 0.800” 0.900” 1.000”

size:8”*0.8”
